PLA-CF Filament
Overview:
QIDI PLA-CF is chopped carbon fiber reinforced PLA FDM material. PLA-CF is easy to print and beginner-friendly like regular PLA. High-quality and affordably priced. The surface of the model will have a carbon fiber matte texture.
- Carbon Fiber Texture & Minimized Layer Lines
- Improved Mechanical Properties
- Stabilized Printing Dimension
Filament Guide(QIDI Wiki)
Recommended printing conditions:
| Recommended Nozzle Diameter | ≥0.4 mm |
| Nozzle Temperature |
210-240°C |
| Print speed | ≤200 mm/s |
| Recommended build surface treatment | PEI Film |
| Build plate temperature | 40-60°C |
| Raft separation distance | 0.08-0.12 mm |
| Cooling fan speed | 80%-100% |
| Retraction distance | 1-3 mm |
| Retraction speed | 1800-3600 mm/min |
| Chamber Temperature | / |
| Additional Suggestions： | |
| After the material is damp, there will be more printing oozing, bubbles extruded and rough printing surface. Please dry the filament in an oven at 50°C for 4-6h to restore the printing quality of QIDI PLA-CF. | |
| Phaetus hardened steel and above grade nozzles shall be selected, which can effectively improve the print quality. | |
